Description
Carbon-PV Panel-type Activated Carbon Module for the ESP-P Series, Deodorizing efficiency ≥90%, air flow capacity 3.000-15.000 m³/h, Pressure drop 150-450 Pa
•V-shaped filter structure: Increases effective air flow cross-section, reduces air velocity, extends contact time, enhances the adsorption efficiency of the activated carbon.
•Support grid design (filter grid): Increases air contact area, reduces pressure drop and power consumption, prevents carbon particle shedding.
•Convenient & economical maintenance: Easy replacement without removal issues, reduces maintenance costs.
•High-quality activated carbon: Lightweight cylindrical type 8#, reduces transport weight, high adsorption capacity.
•User-friendly design: Flexible module, standard flange, resistant to sun and rain, corrosion resistant, IPX4 rated.
•Technical specifications:
Deodorizing rate (%): ≥ 90%
Air flow rate (m³/h): 3000 – 15000
Pressure drop (Pa): 150~450
Dimensions (L×W×H mm): 556×519-2362×575
Activated carbon quantity (kg): 11 – 55
The device is suitable for outdoor environments, easy to install and maintain.
