Name: EH-Return/Exhaust Housing - Airfiltech
SKU: EH-EN

Description

• Wall-mounted return/exhaust air filter housing without face panel, used in cleanrooms or HVAC systems.
• High reliability with a sturdy, durable welded construction.
• Fast filter replacement and easy inspection.
• Integrated differential pressure port to monitor filter condition.

Technical Specifications

Advantages:

Degree reliable reliable high
Structure structure welded robust robust, durable bi
Thay replacement filter quick quickly and easy easy test tra
Integrated compound port measure differential pressure to monitor
Applications: Use tool during cleanroom or system HVAC
Type housing filter: Mounted wall for filter coarse/ filter tinh G4/F7, with air thick 22/48/96 mm
Material material standard: Thickness 1.0–1.2 mm (Hoac depending options different)

Install setting, Construction connect pipe air:

Mounted wall vent via the pore canh is perforated san 4.5 mm by dinh diffusion or upon request
None connection pipe air

Specification Table

Filter Housing G4/F7

Model	Dimensions filter (WfxHfxDf mm)	Dimensions housing (WxHxD mm)	Thickness housing (mm)	Dimensions grille grille (WgxHgxDg mm)	Thickness grille grille (mm)
EH-30460952-SS430	287 x 592 x 22	304 x 609 x 52	1.0	354 x 659 x 10	1.0
EH-60960952-SS430	592 x 592 x 22	609 x 609 x 52	1.0	659 x 659 x 10	1.0
EH-51051052-SS430	495 x 495 x 22	510 x 510 x 52	1.0	560 x 560 x 10	1.0
EH-51060952-SS430	495 x 592 x 22	510 x 609 x 52	1.0	560 x 659 x 10	1.0
EH-41530452-SS430	610 x 287 x 22	625 x 304 x 52	1.0	675 x 354 x 10	1.0
EH-41560952-SS430	610 x 592 x 22	625 x 609 x 52	1.0	675 x 659 x 10	1.0
EH-41577752-SS430	610 x 762 x 22	625 x 777 x 52	1.0	675 x 827 x 10	1.0
EH-41592952-SS430	610 x 915 x 22	625 x 929 x 52	1.0	675 x 979 x 10	1.0
EH-415123452-SS430	610 x 1220 x 22	625 x 1234 x 52	1.2	675 x 1284 x 10	1.0
EH-60960976-SS430	592 x 592 x 48	609 x 609 x 76	1.0	659 x 659 x 10	1.0
EH-30460976-SS430	287 x 592 x 48	304 x 609 x 76	1.0	354 x 659 x 10	1.0
EH-51051076-SS430	495 x 495 x 48	510 x 510 x 76	1.0	560 x 560 x 10	1.0
EH-51060976-SS430	495 x 592 x 48	510 x 609 x 76	1.0	560 x 659 x 10	1.0
EH-62530476-SS430	610 x 287 x 48	625 x 304 x 76	1.0	675 x 354 x 10	1.0
EH-62560976-SS430	610 x 592 x 48	625 x 609 x 76	1.0	675 x 659 x 10	1.0
EH-62577776-SS430	610 x 762 x 48	625 x 777 x 76	1.0	675 x 827 x 10	1.0
EH-62592976-SS430	610 x 915 x 48	625 x 929 x 76	1.0	675 x 979 x 10	1.0
EH-625123476-SS430	610 x 1220 x 48	625 x 1,234 x 76	1.0	675 x 1,284 x 10	1.0

Filter Housing G4/F7 and HEPA/Carbon

Model	Dimensions filter (WfxHfxDf mm)	Dimensions housing (WxHxD mm)	Weight (kg)	Dimensions grille grille (WgxHgxDg mm)	Thickness filter coarse (mm)
EH-680680382-*	610 x 610 x 292	680 x 680 x 382	19	730 x 730 x 10	48
EH-375680382-*	305 x 610 x 292	375 x 680 x 382	15	425 x 730 x 10	48
EH-665665382-*	592 x 592 x 292	665 x 665 x 382	19	715 x 715 x 10	48
EH-359665382-*	287 x 592 x 292	359 x 665 x 382	14	409 x 715 x 10	48
EH-662662382-*	592 x 592 x 292	662 x 662 x 382	19	712 x 712 x 10	48
EH-357662382-*	287 x 592 x 292	357 x 662 x 382	14	407 x 712 x 10	48
EH-662357382-*	592 x 287 x 292	662 x 357 x 382	14	712 x 407 x 10	48
